Chord Electronics
Ultima 2 Mono Power Amp
Ultima 2 is the second mono block in the range, directly below the flagship, and it replaced the SPM 6000 MKII — the amplifier a good many people still consider the high point of Chord's previous generation. Seven hundred and fifty watts into 8 ohms, 1,305 into 4, from the Ultima topology: class AB with sliding bias, dual feed-forward error correction, Chord's own MOSFETs, fully balanced throughout, and convection-cooled so there is no fan to hear. Forty-one kilos and seventy-five centimetres deep, which is a fair warning about the shelf. Choose it over an Ultima 3 when the loudspeakers are genuinely hard to drive rather than merely large. Monoblocks, so a stereo pair means two.
Specifications
| Power output | 750w RMS per channel into 8Ω; 1305w RMS per channel into 4Ω |
|---|---|
| Gain | 30dB |
| Input impedance | 100kΩ Unbalanced/Balanced |
| Output impedance | 0.04Ω |
| Frequency response | -1dB @ 0.2Hz to 46kHz and -3dB 0.1Hz to 200kHz |
| THD | 0.005% |
| Signal-to-noise ratio | Better than -89dB |
| Inputs | 1x Balanced XLR Inverted Input; 1x Balanced XLR Non-inverted Input; 1x Gold Plated Unbalanced RCA Inverted Input; 1x Gold Plated Unbalanced RCA Non-inverted Input; 1x 12v Trigger Input – Chord Electronics Auto Start |
| Outputs | 2x Pair of High Quality, High Current, Gold Plated Type Speaker Terminals (Bi-wireable) |
| Power consumption | Full power – 3000 W; Standby – 10 W |
| Technology | Class AB Sliding Bias; Dual feed-forward error correction; HF Switch Mode Power Supply; Proprietary Chord MOSFETs; Fully Balanced Circuitry; Convection Cooled |
| Dimensions, with Integra legs | 18cm (H) x 48cm (W) x 75cm (D) |
| Dimensions, with side blocks | 15cm (H) x 42cm (W) x 75cm (D) |
| Weight | 41.15kg |
| Finishes | Jett Black, Argent Silver. Legs available in Jett Black, Argent Silver, or Nickel finishes. Gloss black acrylic side block option available. |
| In the box | ULTIMA 2 Quickstart guide; Safety instructions; 15A Mains IEC cable; Included Top Light Ring |
